Home Lab Infrastructure

Boltenhagen, 2023-06-11

I have recently published the full configuration of my home-lab infrastructure on GitHub:


In this post, I will give you a brief overview about the setup.

Design Goals:

  • Quick on-boarding of containerized services.
  • Family members can use the services on any of their devices.
  • No fiddling with IPs and Port names. Services have their own DNS names.
  • Stored data is backed-up safely.

Solution Summary:

  • Services are on-boarded by creating a directory with a docker-compose.yaml and a Makefile.
  • Servies are available on the home network (LAN) and remotely via a Tailscale VPN.
  • Access to services is mainly gated on the network level. Only trusted individuals have access to the LAN and the VPN. Additionally BasicAuth can be added to all web-services with an extra line of configuration.
  • DNS entries are hosted on AWS and configured with Terraform.
    • Services are available under $service.heinrichhartmann.net on the VPN.
    • Services are available under $service.lan.heinrichhartmann.net on the LAN.
    • All web services are secured using https via Let’s Encrypt.
  • Data is stored ZFS on a pair of mirrored HDDs and backed up to Backblaze every night.

The published setup is not intended to be 100% re-usable on the spot. I share this as inspiration for others, that want to get a similar setup going. Also I invite you to provide feedback to me on how to improve.


Host Configuration with NixOS

All services are hosted on a single machine. This configuration is designed to work in different environments including RPI and Linux Desktop machines, but the main server is running NixOS.

NixOS allows the machine to be configured descriptively with a small number of config files. This avoids the need for any bare-metal provisioning tools like Ansible. Moving the setup to a new host is a matter of copying the config files to /etc/nixos/ and running nixos-rebuild.

We use the nix configuration to manage networking, and install a small number of global packages including docker. We also include some basic systemd services that trigger startup and shutdown scripts, as well as a cron target that is executed hourly for maintenance tasks.

Learning Systemd services are very quick to setup on NixOS.

Here is an example config from for promtail:

  systemd.services.promtail = {
    description = "Promtail service for Loki";
    wantedBy = [ "multi-user.target" ];
    serviceConfig = {
      ExecStart =  "${pkgs.grafana-loki}/bin/promtail --config.file ${./promtail.yaml}";
  • Executables are referenced with their package location ${pkgs.grafana-loki}/bin/promtail, and automatically made available in the environment.
  • Config files are referenced from a relative path ${./promtail.yaml} and installed into the /nix tree once the configuration is activated (nixos-rebuild).

Virtual Private Network with Tailscale

In we leverage a tailscale VPN to safely connect to the machine when outisde of the home network. In contrast to traditional VPN solutions, tailscale VPNs don’t need a central hub node that is reachable from the internet. Instead, tailscale establishes direct peer-2-peer connections between participants of the network by traversing NAT walls. A central server is only needed for authentification and with setting up the initial connection.

The central server is configured as a tailscale node, and comes with a static IP address. Tailscale clients are installed on all devices that I use remotely, including iPhones and Android Phones as well as Mac and Linux Laptops.

Learning Tailscale is not entirely frictionless on mobile devices. The Tailscale connections are regularly stopped by the OS, and need to be re-established when I want to e.g. sync Photos to the home-server.

Secret Management with Git-Crypt

Secret management is the first problem that needs to be addressed before we can configure any services. We choose to keep secrets inside the repository using git-crypt.

The trust model works as follows:

  1. On a new host, generate GPG keys and add the public key to the repository, then push to GitHub.
  2. On an already trusted host, pull in the public keys and mark them as trusted, then push.
  3. On the new host, pull latest version. It now has access to the secrets.

Thee steps are automated with a few small scripts. See /crypt/README.md for more details.

Open ends

  • There is no way to revoke keys for the repository at this point in time.

DNS via AWS and Terraform

The configuration now relies on AWS services for DNS.

All required AWS configuration is managed using terraform located in /infra/aws.

  • DNS records for *.heinrichhartmann.net point to the server node inside the tailscale network.
  • DNS records for *.lan.heinrichhartmann.net point to the server node inside the local netowrk.

Learnings. Earlier version of this repository had self-hosted DHCP, DNS and PKI (Private Key Infrastructure for https certificates) included in the config. This has the obvious drawback that all clients have to install a self-signed certificate. But even once this is done, there are more difficulties caused by various clients decided to ignore the DHCP provided DNS services and/or ignore the root certificates installed by the OS. Repeated offenders were Firefox, Firefox on Android, Safari on iPhone.

At some point I stopped trying and accepted the fact, that I will be using an external service for DNS and PKI.

Certificates with Let’s Encrypt

Certificates are generated by Let’s Encrypt and use DNS authentification faciliated by AWS. Generated certificates are stored under /svc/var.

Reneawal is performed using make certs from /svc and triggered every week via cron.

Ingress Proxy with Traefik

Our main host only has a sinlg IP address on each network. To route requests to the correct backend, we use an ingerss proxy that routes requests based on the HTTP HOST header.

We use Traefik for this purpose.

In addition to routing request, traefik terminates HTTPS for us, and provides an optional authentification layer (BasicAuth). Service discovery is dynamic, and configured using labels associated to docker containers.

Example: This is the relevant snippet from a docker-compose file.

      - "traefik.enable=true"
      - "traefik.http.routers.books.rule=HostRegexp(`books.{domain:.*}`)"
      - "traefik.http.routers.books.entrypoints=https"
      - "traefik.http.routers.books.tls=true"

Learnings. Prior iterations used Nginx and HAProxy as for routing requests. I found these solutions harder to maintain, as they required to keep the config files in sync, and the syntax (in particular of HAProxy) was hard to manage. Traefik offers a good out-of-the box experiences for the standard use-cases. Debugging of the docker labels is sometimes a little bit tedious, as there is no linting or syntax checking.

Open ends.

  • I would really like to have OAuth in front of all my services, so I can safely connect and give others the ability to connect without manually managing passwords. Unfortunately the Traefik OAuth plugin is proprietary, and they don’t have pricing information on thier page.
  • At Zalando we maintain an in-house solution Skipper which comes with OAuth support. I want to try this out at some point.

Service Configuration with Docker Compose

Service configurations are stored in ./services/$name they typically consists of two files:

  • A docker-compose.yaml containing the actual service configuration
  • A Makefile exposing targets start, stop, test (defaults can be imported)

Here is a complete example I use for blog.heinrichhartmann.net (see /services/blog for the original).


    name: traefik
    external: true

    image: docker.heinrichhartmann.net/heinrichhartmann.com:latest
      - traefik
      - "traefik.http.routers.blog.rule=HostRegexp(`blog.{domain:.*}`)"
      - "traefik.http.routers.blog.entrypoints=https"
      - "traefik.http.routers.blog.tls=true"
      - "traefik.enable=true"


include /svc/lib/include.mk

Services can be selectively enabled/disabled by adding symlinks to the services.enabled directory. Only enabled services are started on boot.

We provide the following scripts for managing services:

./svc.sh new $name # create new service scaffolding from template

./svc.sh enable $name # enable service with given name

./svc.sh list-available # list available services

./svc.sh list # list enabled services

make start # start all enabled services

make stop # stop all enabled services

make test # test status of all services and print results

Learning. Docker does not provide any facilities to map user-ids from the host to the container. This is a problem when sharing between containers that hold oppinions on which user-id should own files. In our case, the samba service expects files to have owner 1000:1000, and Photo Prism writes files under a differen user-id by default.

To solve this proble we are using bindfs mounts. The reason we need to keep additional Makefiles around, is so that we can manage these bindmounts. Bindfs is a FUSE file system, that allows flexible user-id mappings. FUSE filesystems require a process to run while using the file system, and can’t be configured in fstab. We start the bindfs processes from the make start targets before running docker-compose. Similarly with make stop.

Storage with ZFS

The home-lab server is equipped with 8TB HDD drives for long term storage. Those are configured as a ZFS pool with a mirror configuration, allowing us to compensate for the loss of one of the disks.

  • We use zfs-autosnapshot to protect against accidental deletion.
  • We perform zfs scrubs weekly to protect data against bit-rot.
  • Off-site backup is realized via restic to backblaze for selected datasets.

There are three main filesystems on the pool, that differ in backup and replication strategy.

  • /share/shelf. Data in the attic is snapshotted and backed-up and replicated to working machines. Content includes work-in-progress documents.

  • /share/attic. Data in the attic is snapshotted and backed-up. Content includes archived projects, private photo collection, important media.

  • /share/garage. Data in garage is snapshotted but not backed-up. Here goes the long-tail of less valuable data I wound not too much mind loosing.

The naming of the datasets is reflecting the different storage tiers, that I use for personal stuff:

  • Things in the garage are subject to moisture and my easily get stolen when I inadvertently leave the door open.
  • Things in the attic are safe from the elements. Here I keep things of value that I don’t want to loose.
  • Things on the shelf are used for daily operations, and need to be available at all times.

Learning. Retrieving backups with restic gets extermely slow when keeping around 100s of versions and working over slow networks. Restoring even small amounts of data takes hours to complete. I need to improve the retention policy of the restic backups.

Learning. In recent days I have moved to away from using the shelf dataset and only rely on attic and garage. This is for the following reasons:

  • I moved away from Dropbox for replicating data due to their dropping of zfs support (since reverted), and their questionable product strategy.
  • I lost trust in Syncthing for replication since I suffered multiple painful data-loss incidents.
  • With tailscale I can get access to all files from any network. This grealy reduces the need to keep files around locally.

Next Steps

Working in the monitoring domain, I of-course have a fairly elaborate monitoring/observability setup for my home-lab. In the next post, I am going to walk you thrhough what’s going on there. Stay tuned.
